Copper End Stop Cap End
Copper End Stop Cap End are key metal components for a single fuse in overcurrent protection systems, providing end sealing, axial limiting, and electrical connection. Mounted at both ends of the component body or its holder, these copper parts cooperate with contacts, terminals and busbars to ensure stable positioning and reliable electrical continuity in circuits, while preventing axial displacement caused by vibration or thermal cycling.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Copper End Stop Cap End are core conductive and structural terminals in high-voltage direct current (HVDC), photovoltaic, and industrial fuse assemblies. This product not only serves as the mechanical fixing end of the fuse element and the electrical connection interface to external circuits, but also plays a crucial role in thermal management and arc suppression. In the protection of new energy battery packs, photovoltaic string protection, and short-circuit protection of energy storage systems, the contact resistance stability, temperature rise control capability, and vibration resistance performance of the stop cap directly determine the breaking capacity and operating accuracy of the fuse. This product is specifically designed to meet the harsh operating conditions of automotive-grade (AEC-Q200 reference standard) and industrial applications.
Structural features
Diverse Structural Forms
Employing a cap-shaped or cylindrical structure, the internal cavity dimensions precisely match the fuse end. The end face can be designed as fully enclosed, centrally open, or integrated with the contact blade, suitable for cylindrical, knife-type, and NH-type fuses respectively.
Graded Wall Thickness Design
Wall thickness is optimized in grades based on rated current and breaking capacity. Thin-walled structures are used for low current to reduce material costs, while thicker designs are used for high current and high short-circuit breaking scenarios to ensure thermal stability and mechanical strength.
Clear Specification Range
Wall thicknesses range from 0.8mm to 3.0mm, adaptable to miniature to industrial-grade high-capacity fuses. The coordinated design of wall thickness and internal cavity dimensions ensures stable electrical contact and mechanical limiting functions across different current ratings.
Main functions
Electrical Connection at the End
The copper end stop cap acts as a conductive bridge between the fuse and the external circuit, forming a reliable electrical contact interface with the fuse contacts or end cap. Its conductive cross-section design ensures controllable temperature rise under rated current and sufficient thermal stability under short-circuit current.
Axial Limiting and Positioning
Installed in the fuse holder or clamping structure, the copper end stop cap, in conjunction with a snap ring, elastic clip, or threaded fastener, forms a clearly defined axial stop position, preventing the fuse from loosening under vibration and ensuring that the contact pressure remains within the design range.
End Sealing and Protection
It seals the fuse end, preventing dust, moisture, and conductive foreign matter from entering the fuse interior or contact gaps, reducing the risk of increased contact resistance due to contamination. For applications requiring arc extinguishing, this product, in conjunction with arc-extinguishing materials, forms an effective arc barrier.
Fuse replacement positioning reference
In modular fuse holders or multi-circuit parallel systems, the copper end stop cap can be used as a positioning reference for the fuse insertion depth to ensure consistent installation and avoid poor contact due to insufficient insertion or structural damage caused by excessive insertion.
competitive advantage
The company has passed multiple quality system certifications, including ISO9001-2015, IATF16949, RoHS, and REACH, and has established a full-process quality control and traceability system. With rapid response capabilities and a stable supply chain, it can effectively control supply risks, ensure stable product quality and on-time delivery, meeting the core requirements of engineering procurement. Simultaneously, we possess several industry-recognized patented technologies, focusing on the precision molding, corrosion resistance optimization, and compatibility design of Copper End Stop Cap End. Combined with 30 years of experience in the electrical industry and full-process manufacturing advantages, we have formed a differentiated competitive barrier, ensuring long-term stable product operation and providing customers with more cost-effective customized solutions, demonstrating our core competitiveness.
