Analysis of application technology of high current Insulation coating busbar

Traditional high current distribution projects often use multiple spliced cables and rigid bus ducts, which have problems such as high construction difficulty, insufficient installation flexibility, and high initial investment costs, making it difficult to meet the distribution needs of complex scenarios. The high current Epoxy powder coating insulated busbar is made of high-purity copper wire bar as the core conductor, integrating cable technology and new insulation protection materials. The Insulating coatings busbar is composed of copper wire bar conductor, wrapping layer, insulation layer, metal armor layer and sheath layer, with rated current coverage of 200-6300A, which can be widely used in new energy, power system, industrial and commercial civil buildings, IDC machine room, rail transit, metallurgy, chemical industry, ships and other engineering fields.

The high current Epoxy powder coat busbar has flexible installation adaptability and can meet diverse distribution installation needs. Common installation and connection forms include direct connection of busbar inside the cabinet, top outlet of low-voltage cabinet, horizontal bridge laying, outdoor conduit laying, etc.

In the scenario of line branching and transfer, the extension of the main line can be achieved through T-junction boxes and transfer boxes, supporting on-site branching of T-joints. Pre branch structures can also be customized according to engineering needs. The main line can be laid in an integrated manner without the need for additional joints, effectively improving the overall integrity and stability of the distribution system.

In practical engineering applications, Powder coated busbars need to focus on multiple technical points to ensure the safe and stable operation of the system. This product adopts a drag and drop laying method, and its flat shape is prone to insulation damage during construction. Mechanical protection measures need to be strengthened; Its structural characteristics determine that multi-layer tight laying is not conducive to heat dissipation. When fixing and laying, it is advisable to use vertical arrangement or low-density arrangement to avoid affecting the performance due to poor heat dissipation.

At the same time, strict thermal stability verification must be carried out, and dynamic stability verification should be evaluated in conjunction with the characteristics of Busbar coating with epoxy coating powder. Resonance shaking is prone to occur under short-circuit conditions, and it is recommended to choose products that provide corresponding short-circuit current type test reports to ensure system safety.

To ensure the compatibility of Busbar insulating coating powder with various engineering environments, it is necessary to verify complete type test reports and relevant certifications. The core testing content includes nominal current carrying capacity and protection level verification under different environmental conditions, as well as mandatory industry certifications for fire prevention, flame retardancy, and low combustion emissions. In addition, key electrical performance testing reports such as insulation resistance test, power frequency withstand voltage test, temperature rise test, and short-circuit withstand capability are important basis for the selection and design of Epoxy power coating insulated busbars, which can effectively avoid application risks and ensure the long-term reliable operation of the distribution system.
