Busbar Insulation Paint
In modern power systems, ensuring the safe operation of busbars and efficient power distribution is crucial. Busbar Insulation Paint, a key technology, not only improves system safety but also optimizes space utilization by providing excellent insulation protection for copper or aluminum busbars.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Busbar Insulation Paint is a core insulation component for high-voltage power distribution systems in the fields of new energy and power electronics. It is specifically designed for conductive substrates such as copper bars. Through precise material formulation and standardized coating process, it forms a dense insulation layer on the surface of the busbar, balancing high conductivity conduction with reliable insulation protection. It is suitable for high voltage conditions of 3500VDC to 5000VDC and high current conditions of 100A to 2000A. Its core value lies in providing engineering procurement and system engineers with a full-chain insulation solution that is "technically compatible, reliable in the long term, consistent in batches, and controllable in supply". It supports the efficient and stable operation of new energy vehicles, photovoltaic energy storage, power appliances and other scenarios, and helps to achieve cost reduction, efficiency improvement and sustainable development goals.
Process Flow
Substrate Pretreatment
Copper and aluminum busbar substrates undergo standardized treatment including degreasing, rust removal, and drying to remove impurities and oxide layers, improving cleanliness and laying a solid foundation for stable coating adhesion, thus avoiding delamination and blistering.
Insulating Varnish Formulation
Insulating varnish is precisely formulated according to standard recipes to match engineering conditions, strictly controlling viscosity and component uniformity. After degassing, batch-to-batch consistency in insulation performance and coating effect is ensured for Busbar Epoxi Powder Coating.
Precise Coating Operation
Automated equipment is used, and corresponding coating processes are selected based on busbar specifications. Coating thickness is precisely controlled, and parameters are monitored throughout the process to ensure a dense, uniform coating free of appearance and performance defects.
Curing and Inspection before Shipment
The Busbar Coating with Epoxy Coating Powder undergo standardized curing treatment to enhance coating adhesion. Multiple tests are conducted to eliminate substandard products, ensuring that products meet international standards before shipment.
Technical parameters
Busbar Resistance Compatibility: The product is compatible with copper bars, stably controlling the busbar resistance to ≤0.00001Ω, meeting the requirements for efficient conductive transmission.
Load Voltage Range: The Busbar Insulating Coating Powder is suitable for high-voltage conditions from 3500VDC to 5000VDC, meeting the insulation protection requirements of high-voltage power distribution systems.
Load Current Range: The Busbar Coating can carry currents from 100A to 2000A, adapting to the power transmission requirements of different power scenarios.
Assembly Fixture Compatibility: The Busbar Epoxi Powder Coating is compatible with PEM stainless steel nuts, studs, and other fixtures from the USA, facilitating engineering installation and integration.
Temperature Resistance Specifications: Standard models withstand temperatures from -73℃ to 180℃, while customized high-temperature models can reach up to 1800℃, suitable for various environments.
Dielectric Strength Standard: The Powder Coating Insulation Busbar's dielectric strength is ≥10⁴KV/m, providing robust insulation protection in high-voltage scenarios.
(Note: Specific parameters can be designed and customized according to customer product requirements)
Application scenarios
New Energy Vehicle
In new energy and hybrid vehicles, the Epoxy Powder Insulated Bending Copper Busbar is compatible with high-voltage power distribution connections for film capacitors and battery packs, providing lightweight and compact insulation solutions to ensure the safe operation of on-board high-voltage systems and effectively save installation space.
01
Photovoltaic Energy Storage
The product can provide busbar insulation protection for photovoltaic inverters and energy storage battery compartments, resisting the effects of complex environments such as outdoor humidity and temperature fluctuations, ensuring efficient transmission of renewable energy, and facilitating the large-scale deployment of photovoltaic systems.
02
Power and Electrical
In power equipment such as distribution cabinets and switchgear, the Copper Busbars at Coating can meet the insulation requirements of high-current, high-voltage power distribution, optimize the internal space layout of equipment, and further improve the stability and security of power distribution.
03
High-End Industrial
In high-end power systems such as rail transit and cloud server uninterruptible power supplies, the Epoxy Coating Powder Busbar is suitable for high-frequency, high-load operating conditions, reducing equipment maintenance costs with long-term reliability and providing support for industrial automation upgrades.
04
Why Choose Us
With 30 years of experience in the electrical industry, independent control over all production processes, and a global service network, we can provide you with Busbar Insulation Paint products that are precisely tailored to your technical needs and offer long-lasting, stable quality. Relying on customized solutions, collaborative support across the entire industry chain, and efficient supply chain management, we balance cost reduction and efficiency improvement with compliance, precisely meeting the core requirements of engineering procurement and technology selection in the new energy and power electronics fields, providing reliable assurance for the stable operation of high-voltage power distribution systems.
Contact Us
If you have any needs regarding the procurement, selection, sample request, or customization of Busbar Insulation Paint, or if you wish to learn more about the product details, please feel free to contact us. We will arrange a professional team to provide one-on-one service, customize adaptation solutions, and ensure stable supply, accurate selection, and efficient procurement.
