DC Support Capacitor Laminated Bus Bars
DC Support Capacitor Laminated Bus Bars are engineered components of copper layers separated by thin dielectric materials. They provide low inductance connections for capacitors and are suitable for high-current, high-speed switching applications. The laminated structure offers space efficiency, easy assembly, enhanced electrical properties, improved current carrying capacity, and better thermal performance. These bus bars are widely used in laminated inverter busbars, variable-frequency drives, and various industrial applications.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
DC Support Capacitor Laminated Bus Bars are engineered components designed to provide efficient electrical connections in power systems. These Laminated BusBars consist of multiple layers of conductive material (typically copper) separated by thin dielectric insulating materials, forming a compact, unified structure. The laminated design offers space efficiency, easy assembly, enhanced electrical properties, improved current-carrying capacity, and better thermal performance compared to traditional wiring solutions.
Material Advantages
Conductive Layers
Made from high-purity copper (typically T2 grade), these layers provide excellent electrical conductivity with low resistivity, ensuring efficient power transmission and minimal energy loss for Laminated Copper BusBar.
Insulating Layers
Utilize high-performance materials for Laminated Busbar Connectors such as PET (polyethylene terephthalate) or NOMEX, which offer superior dielectric strength, thermal resistance, and mechanical durability while preventing electrical short circuits between conductive layers.
Plating Options
Available with tin, nickel, or silver plating to enhance corrosion resistance and improve connectivity.
Product Parameters
Dimensions
Customizable to fit specific application requirements, with a maximum working size up to 2000mm x 1200mm.
01
Current Rating
Ranges from 0 to 4000A, depending on the specific design and application.
02
Voltage Rating
Varies based on insulation material and thickness, with options for both low-voltage and high-voltage applications.
03
Inductance
Designed to achieve low inductance values, critical for high-frequency switching applications.
04
Thermal Performance
The large surface area and conductive materials provide efficient heat dissipation, maintaining optimal operating temperatures even under high loads.
05
Product Applications
| Laminated Inverter Busbars | Used in solar inverters and other power conversion systems to connect capacitors, IGBTs, and other critical components with low inductance paths. |
| Laminated Bus Bar for Variable Frequency Drive | Integrated into VFD systems to provide reliable power distribution with minimal electromagnetic interference. |
| Laminated Bus Bar for Industrial | Applied in various industrial settings, including motor drives, welding systems, and factory automation equipment, where compact, high-current connections are required. |
Customer Praise and Feedback
Our customers consistently praise our DC Support Capacitor Laminated Bus Bars for their:
Reliability: Exceptionally low failure rates in demanding industrial and automotive applications.
Performance: Superior electrical characteristics that enhance overall system efficiency.
Customization: Ability to design and manufacture bus bars to precise specifications.
Quality Control: Rigorous testing procedures, including HiPot and Partial Discharge tests, ensure each unit meets performance standards.
Lead Times: Competitive production schedules that support project timelines without compromising on quality.
contact us
