Laminated Busbar Solutions
Laminated busbar is a key component of modern power systems. It integrates conductivity, insulation, heat dissipation and other functions, optimizing the power transmission path. Manufactured using advanced technology, it has high reliability and long service life, and is widely used in new energy vehicles, industrial automation and other fields.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Profile
Laminated busbar solutions integrates material science and advanced manufacturing technology to achieve efficient and safe power transmission. It can work stably under different voltage and current levels, adapt to various harsh environmental conditions, and ensure the continuity of power supply. Product design focuses on heat dissipation performance, and through reasonable structural design and application of heat dissipation materials, the operating temperature of the equipment is effectively reduced.
Product parameters
Product materials
Rated current
Depending on the model, the rated current ranges from 10A to 1000A. For example, small laminated copper busBar are suitable for low-power equipment, with rated currents ranging from 10 to 50A; medium-sized laminated busbars are often used in general power equipment, with rated currents ranging from 50 to 300A; large laminated flexible busBar are aimed at high-power equipment, with rated currents of 50-300A. The current can reach 300-1000A, meeting the power transmission needs of various power equipment.
Rated voltage
Supports rated voltages from 36V to 1000V. Among them, in common low-voltage application scenarios, the rated voltage is 36V - 48V, which is suitable for some small electronic equipment and control systems; in the industrial and new energy fields, the commonly used rated voltage is 220V - 400V; for some special high-voltage equipment, stacked The layer busbar can support rated voltages from 600V to 1000V and can adapt to power systems of different voltage levels.
Insulation resistance
Insulation resistance is up to 1000MΩ. Under normal working conditions, such a high insulation resistance can effectively prevent current leakage, ensure reliable insulation performance in high-voltage environments, and ensure the safety of equipment and personnel.
Operating temperature range
It can work normally in a wide temperature range of -40℃ to 125℃. In low-temperature environments such as cold outdoors or low-temperature industrial places (-40°C), the materials and structures of the laminated busbar design can still maintain stable performance; in high-temperature environments such as inside some equipment that generates large amounts of heat (125°C), they can also ensure The stability of power transmission can adapt to various harsh environments.
Product advantages
packaging and transportation
| Packaging Protection | Use professional packaging materials, such as anti-static bags, foam, cartons, etc., to provide multi-layer protection for the laminated busbars to prevent damage during transportation. |
| Various Transportation Methods | According to customer needs, various transportation modes such as road, railway, and air can be selected to ensure that laminated copper busbar are delivered to their destinations on time and safely. |
workshop advantages
Advanced equipment
Equipped with internationally leading production equipment, such as high-precision automated lamination machines, laser cutting machines, etc., to ensure laminated flexible busbar processing accuracy and production efficiency.
Clean production environment
The workshop adopts a dust-free, constant temperature and constant humidity production environment to effectively prevent dust, humidity and other factors from affecting laminated busbars quality.
Professional technical team
We have an experienced and skilled professional team with full-process technical capabilities from laminated bus bar design to production and manufacturing.
Strict quality management system
A complete quality management system has been established, and strict quality control is carried out in every link from raw material procurement to product delivery.
Compared with traditional wiring methods, laminated busbars can significantly improve power transmission efficiency, reduce energy loss, and reduce system costs.Its standardized design and modular structure facilitate installation and maintenance, providing users with a convenient experience.
