Motor Drive Laminated BusBar For Power Electronics
This product is a Motor Drive Laminated BusBar for Power Electronics specifically designed for electric drive systems (E-Drive) of new energy vehicles, industrial frequency converters, and photovoltaic inverters. The product is integrally formed by hot-pressing composite process using multiple layers of high-conductivity copper busbars and high-performance insulating films, aiming to solve the problems of parasitic inductance suppression, electromagnetic compatibility (EMC) optimization, and power distribution in compact spaces under high-frequency switching conditions.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Motor Drive Laminated BusBar for Power Electronics are core conductive connection and power distribution devices in electric drive systems (inverters, frequency converters, motor controllers, etc.) in the power electronics and new energy fields. Their core function is to achieve efficient transmission and precise distribution of high voltage and high current within the electric drive system, while ensuring electromagnetic compatibility (EMC) performance and structural compactness. Compared to conventional laminated busbars, this product focuses on high-frequency, high-voltage, and high-current operating conditions in electric drives, with specifically optimized insulation reliability, current distribution uniformity, and structural integration. It is compatible with 800V high-voltage platforms and multi-functional electric drive systems. Leveraging the company's full-industry chain advantages and extensive electrical experience, it provides integrated services from parameter customization to mass production, reducing selection and procurement costs.
Structural design
Layered Conductive Layout
Employing a 2-8 layer parallel layout of high-purity copper foil/copper busbars, with precise interlayer spacing controlled between 0.1-0.5mm, and isolated from signal lines via positive and negative busbars, significantly reducing distributed inductance and parasitic capacitance. This design is compatible with the high-frequency switching characteristics of SiC and IGBTs, achieving high current sharing, reducing localized overheating, and ensuring stable and efficient power transmission in the electric drive system.
High-Performance Insulation System
Utilizing PI or epoxy resin insulating film as the core insulation layer, with a thickness customized from 0.05-0.2mm according to voltage rating, and a breakdown voltage ≥15kV/mm, meeting the high-voltage requirements of 800V and above. Vacuum hot-pressing ensures a tight, gapless bond between the insulation and conductive layers, resisting temperature cycling and vibration shocks, eliminating the risk of interlayer peeling and insulation breakdown.
Customized Terminal Interfaces
The end terminals are made of high-purity copper, the same material as the conductive layer, and are integrally stamped and welded. Various structures can be customized according to customer drawings. Terminal tolerance is ≤±0.02mm, ensuring seamless connection between the Transportation Locomotive Power BusBar and various components of the electric drive system, reducing installation steps and contact resistance, and lowering the probability of failure.
Application areas
New Energy Vehicles - Capacitor DC Bus
Designed for the compact layout and high-frequency pulse conditions of EV capacitor DC LINK systems, this Traffic Tram Electric BusBar boasts a low distributed inductance of ≤5nH, perfectly adaptable to bus capacitor and inverter connections. Its integrated laminated structure resists multi-directional vehicle vibrations, customized terminals enable gapless installation in confined spaces, and low parasitic parameters reduce voltage spikes, ensuring stable DC bus power transmission.
Photovoltaic Inverters - Power Connection
Adapted to the high-temperature and high-humidity outdoor environments of PV inverters, this product employs a high-temperature resistant insulation system and a high-purity conductive layer. The UV-resistant insulation layer withstands long-term aging, and precise interlayer bonding prevents delamination due to temperature differences. Customized high-current terminals enable efficient heat dissipation and stable current carrying capacity in string and centralized inverters, meeting the high-power photovoltaic power generation requirements for Web Server BusBar.
Power Electronic Devices・Core Power Distribution
Designed for equipment such as UPS, PDU, APF and SVG, the product's modular structure is seamlessly compatible with the internal copper busbars. Its high-precision dimensions are suitable for dense power distribution unit installations. Its excellent electromagnetic interference resistance is suitable for harmonic control conditions. High mechanical strength welded terminals ensure stable connections during frequent UPS switching, making it a reliable core power distribution component.
Our factory
Leveraging the company's group-wide layout and full-industry chain advantages, product manufacturing achieves independent control over core processes and full traceability of quality, adapting to the needs of large-scale, stable, and low-cost engineering procurement. It also leverages the unique characteristics of Motor Drive Laminated BusBar for Power Electronics to create exclusive manufacturing advantages. The company has modern factories in Ningbo and Xiamen, equipped with core equipment such as automated laser cutting and vacuum hot-pressing lamination. Strictly adhering to relevant quality systems, the company focuses on precision machining and mass production, utilizing the industrial advantages of both locations to ensure supply efficiency, rapidly respond to global customer needs, and ensure that every batch of products meets quality standards.
Contact Us
For inquiries regarding Motor Drive Laminated BusBar for Power Electronics specifications, customization options, samples, delivery time, and pricing, please feel free to contact us.
