PCB Bus Bars
In high-power-density electronic systems, PCB Bus Bars are an innovative electrical interconnection solution that deeply integrates traditional laminated bus bar technology with printed circuit board (PCB) technology. It is not a simple copper bar replacement, but a precision functional carrier that integrates high current transmission, signal integrity management, thermal field optimization and structural integration.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
As new energy vehicle electric drive systems, energy storage converters (PCS), industrial servo drives and high-performance computing power modules evolve towards miniaturization and high integration, traditional cable bundles and discrete copper bars are no longer able to meet space constraints and electromagnetic compatibility (EMC) requirements. PCB Bus Bars achieve planar reconstruction of the power path by embedding a thick copper layer or a special stacking design of the surface layer inside the multi-layer PCB.
Product nature and core features
Inter-layer integrated design
Using a multi-layer lamination structure, the positive and negative electrodes, phase lines and ground layers are integrated into a single BusBar for Siemens component, eliminating the external wiring node.
Embedded power channel
Supports inner thick copper (up to 20oz or more) to achieve a planar conductive path with low impedance and high current carrying capacity for BusBar in Substation.
Optional rigid-flexible combination
According to system layout requirements, an integrated molding solution for the rigid area (fixed installation) and flexible area (dynamic connection) can be provided.
Common board integration of power and signal
High-current power layer and a low-voltage control signal layer can be laid out simultaneously on the same substrate, reducing system-level interconnection complexity for Industrial BusBar.
Built-in filtering and shielding structure
Optimize electromagnetic interference (EMI) performance in high-frequency switching environments through ground layer segmentation, copper slotting and distributed capacitor design.
Thermal-electrical collaborative design
Combining copper sheet distribution and thermal via (Thermal Vias) layout to achieve directional conduction of power loss and optimization of heat dissipation paths for Tinned Copper BusBar.
Detailed display
We encourage our customers to examine our products in detail. Under the microscope, our PCB busbars show the texture of industrial art.
Smooth edges
The edges of the etched copper bars are smooth and burr-free, eliminating tip discharge under high voltage for
BusBar in Substation.
01
Full coating
The surface treatment layer is uniform and dense with consistent color, ensuring extremely low contact resistance and long-term solderability for Industrial BusBar.
02
Clear silk screen printing and markings
Accurate polarity markings and safety distance markings provide great convenience for your automated assembly and subsequent maintenance.
03
Tight coating
For the exposed busbar part, we can provide insulation film coating or an injection molding process to provide IP67 level protection capability for BusBar Electric.
04
Typical application scenarios
New energy vehicles
Motor controller (Inverter), on-board charger (OBC), and main power bus in a DC-DC converter for Power Bar BusBar.
Energy storage and photovoltaic systems
Battery cluster confluence, PCS DC side bus, MPPT module internal power connection for High Current Contacts.
Industrial automation
Power interconnection of high-power servo drives, frequency converters, and UPS power modules.
Rail transit and special power supplies
Traction converters, high-voltage busbar components in auxiliary power systems for Copper Busbar Manufacturer.
Why Choose Us
Engineering Capabilities and Delivery Guarantee.
Deeply engaged in the field of power electronics interconnection
We have a full-process engineering team from conceptual design, simulation analysis to mass manufacturing for Copper Busbar Manufacturer.
Flexible customization capabilities
Regardless of sample verification or small batch trial production, we can quickly respond to customers' non-standard needs for Tinned Copper BusBar.
Strict quality system
It complies with the ISO quality management system and can implement IPC-A-600, IPC-6012 and other standards according to customer needs for BusBar Electric.
Global delivery experience
Familiar with the engineering language and compliance requirements of international customers, and supports cross-border project collaboration.
contact us
If you are looking for a customized PCB Bus Bars solution that can increase system power density and ensure continuous and stable operation, you are welcome to submit your design requirements to our engineering team, and we will provide you with professional DFM evaluation and technical support.
