Distribution Busbar For Automotive



The Distribution Busbar for Automotive is typically constructed from tin-plated copper or bare copper, which provides excellent electrical conductivity. The copper bar serves as a carrier, efficiently transferring total current to various components or charging the current as needed. These busbars play a crucial role in reducing overall system costs while enhancing reliability and performance. By minimizing wiring errors, they simplify the design and installation process. Furthermore, they help lower inductance and increase capacitance, making them ideal for high-performance applications. For instance, the Tin Plated Electric Vehicle Bus Bar is specifically designed to meet the needs of electric vehicles, ensuring optimal current flow. Additionally, the EV Motor Control Busbar plays a vital role in managing power distribution within the motor control system, further enhancing the efficiency of electric vehicles.







Features of Distribution Busbar for Automotive include but are not limited to the following:



	1.	Minimal impedance and voltage drop.
	2.	Strong overload capacity.
	3.	Reduction of the harms caused by peak voltage to the components and extension of the service life of the electronic components.
	4.	Reduction of the system noise and the electromagnetic interference/radio frequency interference.
	5.	Easy installation and convenient on-site maintenance.
	6.	Fewer components and improvement of the system reliability.
	7.	Equally distributed capacitance







Mechanical Properties

Trade mark	Supply status	Tensile test results		Hardness test results
		Tensile Strength	Elongation	HV	HRF
T2	Hot rolling(R)	≥195	≥30	-	-
	Soft(M)	≥195	≥35	-	-
	1/8Hard(Y8)	215～275	≥25	-	≥50
	1/2Hard(Y2)	245～335	≥10	75～120	≥80
	Hard(Y)	≥295	≥3	≥80	≥65



Electrical Properties

Trade mark	electrical conductivity/%IACS	electrical resistivity/(Ω▪mm2/m)
TU1	≥100	≤0.017241
T2	≥98	≤0.017593









Distribution Busbar for Automotive is used in a wide range of applications, probably in the following areas:



1.	Power electronics	Frequency converters, inverters, current transformers, active filters, uninterruptible power supplies, laser power supplies.
2.	Transportation	Electric locomotives, electric boats, traction equipment.
3.	Aerospace	Satellite systems, missiles, space shuttles, space stations.
4.	Military	Armored vehicles, radar systems, missile systems, submarine power systems, communications and command systems.
5.	Communication	Telephone exchange systems, 5G network equipment, communication base stations, large network equipment.
6.	Medical equipment	Diagnostic equipment, X-ray equipment, MRI equipment, medical laser equipment.
7.	Others	Host, power generation system, welding system, electrical equipment.





Welcome to our "world"! Do you have any questions, or suggestions or want to know more about us? Please feel free to contact us, we are looking forward to your "voice"!



The automotive distribution busbar is made from tin-plated copper or bare copper, offering excellent conductivity and corrosion resistance for long-term stability. Its lightweight design helps reduce vehicle weight, improving fuel efficiency. The busbar effectively lowers inductance and increases capacitance, ensuring stable current transmission, making it a key component widely used in electric vehicles and traditional automotive electrical systems to enhance overall performance.
