Copper Stamping Electrical Parts
Copper stamping electrical parts are core conductive and structural components formed by precision stamping of copper materials, widely used in fields such as electronics, electrical, new energy, and automobiles. They are the core conductive connecting components of low-voltage electrical equipment such as switches, circuit breakers, relays, and contactors.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
In critical electrical equipment like electrical switches, circuit breakers, and relays, the performance of core conductive and heat-conductive components plays a decisive role in the overall device's current-carrying capacity, temperature rise control, and operational lifespan. Developed specifically for the low-voltage electrical, new energy, and industrial control sectors, this line of Copper stamping electrical parts is crafted by processing high-quality copper materials into custom-shaped, precision-sized metal components via advanced high-precision stamping technology. Serving as essential elements for current transmission, contact support, and mechanical connection, these stamping parts are extensively applied in switch contact bridges, circuit breaker conductive systems, relay armatures, and terminal connection assemblies.
Core strengths
High precision and high consistency
Through advanced mold design and precision stamping technology, the conventional dimensional accuracy can reach ± 0.05~± 0.1mm, and high-precision products can be controlled within ± 0.01mm, ensuring that the size, shape, and height of each Copper stamping electrical parts are consistent in mass production, and can meet precision assembly requirements without secondary processing, suitable for large-scale production.
01
Excellent electrical and thermal conductivity
Copper sheet stamping has a conductivity of ≥ 97% IACS, making it one of the most conductive copper materials. It can minimize current transmission losses and contact temperature rise, ensuring stable operation of electrical equipment; Simultaneously possessing excellent thermal conductivity, it is suitable for scenarios such as heat dissipation modules and high-power electrical components.
02
Good mechanical properties
Different copper alloys endow Electrical copper stamping parts with differentiated mechanical properties: purple copper has excellent toughness and is suitable for the fatigue resistance requirements of repeated on-off cycles; Brass has high strength and is suitable for structural component scenarios; Bronze has high hardness and is suitable for wear-resistant scenarios, meeting the stable operation requirements under various complex working conditions.
03
Strong design flexibility
It can be processed into various complex shapes through mold changes, from ultra-thin copper foil pieces of 0.1mm that are widely used in flexible circuit boards and miniature electronic components to thick walled pieces of 10mm or more that are applied in large-scale electrical equipment and mechanical structural parts, and from simple flat plates for basic conductive connection and gap adjustment to complex three-dimensional structures with bending, stretching, punching, bosses and other composite features.
04
production process
Raw material preparation: We use high-quality pure copper (purple copper) that meets international standards, and can provide copper alloys such as brass/bronze as needed; All raw materials are tested for conductivity, hardness, tensile strength, and other properties. Copper coils are precision cut into standard billets, and then subjected to surface pretreatment of Metal stamping parts electric copper to remove oxide layers, oil stains, and impurities, ensuring stable stamping and consistent material properties.
Mold development: Customize specialized stamping dies based on the shape, size, and tolerance requirements of Copper stamped components, using high-strength wear-resistant die steel such as Cr12MoV, and manufactured through precision processes such as CNC machining and electrical discharge machining; Complex structural components are formed in one go using multi process composite molds, and each mold undergoes strict mold calibration before production to ensure stability and accuracy in mass production.
Stamping forming: The preprocessed copper billet is fed into high-precision stamping equipment, where pressure, speed, and stroke are precisely controlled through customized molds to complete forming processes such as punching, bending, stretching, and deep drawing, minimizing internal stress, rebound, and defects; It can achieve ultra-high dimensional accuracy of ± 0.01mm, ensuring consistency in batch Copper strip stamping and adapting to automated assembly requirements.
Surface cleaning and post-treatment: Stamping parts undergo ultrasonic cleaning, alkaline degreasing, and multiple rinses to thoroughly remove stamping oil, metal shavings, and other residues; It can be equipped with post-treatment processes such as passivation (anti oxidation discoloration), tin/silver plating (improving weldability and corrosion resistance), polishing (optimizing surface finish), etc. as needed, with strict control throughout the process to ensure that the product meets industry performance standards.
Finished product testing and packaging: Each batch of Cross copper metal stamping undergoes comprehensive testing, with high-precision measuring tools verifying dimensions, optical equipment investigating surface defects, and conductive components completing electrical performance and material verification; Qualified products are packaged in moisture-proof, oxidation resistant, and anti-static professional packaging, suitable for international long-distance transportation. At the same time, neutral packaging and customized packaging solutions can be provided to ensure storage and transportation safety.
Application scenarios
Electrical switches field
Copper spring contacts are widely used in household, commercial, and industrial wall switches, socket modules, and internal structural components of smart switches. As the core carrier of switch contacts, these stamped parts are responsible for the connection and disconnection of circuits, ensuring stable current transmission under the touch switch, and solving problems such as ignition and failure caused by poor contact.
Circuit Breakers field
It is the internal core conductive component of power distribution equipment such as miniature circuit breakers (MCBs) and molded case circuit breakers (MCCBs). The special-shaped copper stamping structure precisely adapts to the electromagnetic release, conductive bridge, and terminal system inside the circuit breaker. Its core function is to quickly disconnect the circuit in case of overload, ensuring electrical safety.
Contactors&Relays field
Copper stamping China factory is used for the internal copper contacts and armature brackets of AC contactors, DC contactors, and various electromagnetic relays. The copper stamped coil frame in the upper left corner of the picture and the conductive spring on the right side are the core components of the contactor, used for high-frequency current conduction and magnetic field response, ensuring the sensitivity and stability of the electrical control system.
Low voltage distribution and industrial control
Extended adaptation to small distribution boxes, terminal distribution boxes, motor control circuits, and other industrial scenarios. Electrical control terminals in various high and low temperature environments rely on Copper stamped electrical contacts to construct internal power networks, ensuring precise connection between signals and electricity.
Our Certifications
Between the surging current of photovoltaic modules and the surging energy of energy storage batteries, Xiamen Apollo Stamping Welding Technology Co., Ltd. has built a quality moat with global certification and exclusive patents. We have not only obtained ISO 9001:2015 international certification (currently applying for IATF16949 automotive industry international quality certification system), but also redefined the precision and reliability of Copper stamping electrical parts with three core patented technologies.
contact us
Xiamen Apollo Stamping Welding Technology Co., Ltd is a professional service provider for new energy metal processing solutions. We can help you accurately match your needs and maintain the bottom line of device safety. Welcome to consult us.
