Aluminum Electrical Power Connector For Busbar
Aluminum Electrical Power Connector For Busbar is a metal connection component specially used to achieve detachable electrical connections between aluminum busbar systems or between busbars and other electrical equipment. This product uses aluminum alloy as the base material and is formed by casting, forging, extrusion or machining. It is combined with anti-electrochemical corrosion surface treatment and anti-loosening fastening structure to achieve low contact resistance, high mechanical strength and reliable electrical connection for long-term operation.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Aluminum Electrical Power Connector For Busbar
It is a high-performance conductive connection component specially designed for busbar interconnection in power systems, integrating reliability, adaptability, and cost-effectiveness. Made of high-purity 1060 aluminum alloy as the core material, it features excellent electrical conductivity, low resistivity and lightweight performance, which is 70% lighter than copper connectors, effectively reducing the structural load of power equipment and improving installation efficiency.
Product properties and characteristics
Our aluminum busbar power connector is essentially an electrical interface optimized for high current, high mechanical strength applications. Its core feature is the perfect balance between material performance and structural design.
High-strength aluminum alloy body
Abandoning the softness of traditional pure aluminum, we choose 6061-T6 high-strength aluminum alloy that has undergone special heat treatment. While maintaining excellent electrical conductivity, this material has excellent mechanical strength and creep resistance. It can withstand thermal expansion, contraction and electromagnetic impact during long-term operation.
Bi-metal compatible design
The product has CU9AL dual-rated certification, which means it can safely and reliably connect copper busbars and 6101 t61 aluminum bus bars, or copper/aluminum cables. This solves the corrosion problem caused by electrochemical potential differences when connecting different metals, and provides great flexibility in system design and material selection.
Modularity and scalability
The connector adopts a modular design and supports a variety of installation methods and conductor specifications. Whether Electrical Aluminum Busbar Flexible Joint is a single hole, double hole, or slotted hole installation, it can be easily adapted to meet the diverse wiring needs from simple branches to complex confluences.
Material advantages
Aluminum alloy grade
Choose 6101B or 6063-T6, which has higher yield strength and creep resistance than industrial pure aluminum for the 6101 aluminum bus bar.
Grain refinement treatment
Complete annealing + aging process after extrusion to eliminate internal stress and prevent intergranular micro-cracks after long-term energization for 6101 t61 aluminum bus bar.
Contact layer material
Tin plating layer: suitable for dry environments and cost-controllable. Silver plating layer: suitable for high humidity, high corrosion, or frequent thermal cycle scenarios.
Manufacturing process
Financial Big Data
The key force-bearing and conductive parts adopt a multi-directional precision die forging process to ensure complete metal streamlines and continuous fiber structure. The mechanical properties are greatly improved compared with traditional casting or machined parts, and there are no internal defects, ensuring that each product has highly consistent performance.
CNC precision machining
All mounting holes and contact planes are clamped using a multi-axis CNC precision machining center to ensure extremely high dimensional accuracy, geometric tolerances and surface finish. This is the manufacturing basis for achieving uniform pressure distribution and low and stable contact resistance.
Fully automated surface treatment line
From cleaning, passivation, coating, to drying, everything is completed in the automated production line, minimizing manual intervention points to ensure uniform coating thickness, strong adhesion, no pollution, and batch consistency reaching the top level in the industry.
Application advantages
DC connection inside the energy storage container
Anti-vibration structure, passed IEC 61373 shock and vibration test. The telescopic type compensates for the relative displacement between the battery cluster and the converging cabinet.
Industrial plant upgrades
When the original copper busbar is changed to an Electrical Aluminum Busbar Flexible Joint, this connector is used as a copper-aluminum transition piece, and there is no need to replace all equipment terminals.
Photovoltaic power station combiner box and inverter connection
The outdoor connector uses double-layer heat shrink tubing + sealing rubber ring, with a protection level of IP65 for 6101 t61 aluminum bus bar.
Rail transit traction power supply system
Use non-magnetic stainless steel bolts to avoid eddy current heating. Long-span telescopic connectors are used in steel-aluminum composite rail systems for the Aluminium Busbar Manufacturer.
contact us
We know that what you purchase is not just a connector, but also the safety and performance of the power system of the project you are responsible for in the next ten or twenty years. We not only provide Aluminum Electrical Power Connector For Busbar that meet standards, but also provide reliable solutions based on deep engineering understanding and precision manufacturing capabilities. Let us use our expert engineering capabilities to build a solid electrical connection foundation for your next critical project.
