Automated Electronic cabinet wiring process and practical points

Standardized and neat Outdoor electrical cabinet wiring not only enhances the overall appearance and texture of the equipment, but also significantly improves the efficiency of troubleshooting in the later stage. It is a crucial link in the assembly of automated equipment.
Taking the common board driven stepper motor system as an example, a single board is paired with multiple stepper motors and multiple sensors. Although the wiring principle of the Outdoor weatherproof enclosure cabinet box is not complicated, it requires extremely high attention to detail and patience from operators in order to achieve standardization, aesthetics, and easy maintenance.

Wiring is a delicate task that requires strict attention to detail. Practitioners need to have sufficient patience and focus. From the actual construction situation, operators with delicate minds often have an advantage in the quality and regularity of Electrical cabinets and enclosures wiring.

The internal layout of the Electrical cupboard needs to be determined in conjunction with mechanical design and electrical control requirements.

Firstly, the cabinet functions should be clarified, standard components should be selected, and the dimensions and installation methods should be checked.

After the layout plan is determined, it is recommended to synchronously complete the drilling and positioning during the installation board cutting stage, which can effectively avoid problems such as deviation and component skewing in the later on-site hole matching, and ensure the overall beauty and regularity of the Electrical cabinet outdoor.

The panel openings also need to be planned in advance, and the positions of switches, power supplies, Ethernet ports, aviation plugs, serial ports, and instruments need to be determined at once. Split type panels can be processed by laser cutting, while integrated Exterior electrical cabinet panels can only be drilled on site, which is not only cumbersome to construct, but also easily affects the integrity of the appearance.

Accurate control of wire length is required for wire laying to avoid excessive redundancy. Winding excess wires inside a Switching cabinet can take up space, especially in compact cabinets, which can affect wiring and maintenance.

The core function of wire number identification is to facilitate fault diagnosis, rather than formal installation. The aviation plug lead wires need to be clearly labeled with pin definitions, and power lines such as 24V, 0V, GND need to be labeled with corresponding axis numbers to adapt to multi axis control scenarios in Electrical enclosure cabinets.

In multi axis control systems, centralized terminals such as pulse, limit, and origin cannot be simply numbered with numbers, otherwise it will cause confusion and difficulty in troubleshooting Electrical enclosure cabinet circuits. Standardized identification, like code comments, is an important basis for later maintenance.

The stripping length should match the terminal. If it is too short, it will cause weak crimping and easy detachment. If it is too long, it will affect the installation of the Control cabinet enclosure terminal block and increase unnecessary working hours.

Before crimping, multiple strands of wire should be twisted neatly, and a suitable wire stripping blade should be selected to avoid cutting thin strands of wire that may affect the current carrying and crimping effect. The crimping needs to be compacted multiple times and subjected to tensile testing to ensure that the Contactor cabinet wiring is secure.

When wiring, excess wires should be trimmed to avoid random winding. The wires should be accurately inserted into the inner side of the terminal clamp, tightened, and checked again for tension to ensure reliable and stable internal wiring of the Electrical cabinet assembly.
