Laminated busbars: A core solution for efficient and reliable power distribution backplanes, facilitating upgrades to new energy and industrial power systems

Laminated busbars play a vital role in modern power electronics systems. As a core power distribution component, their performance and reliability are directly related to the efficient operation of the entire power system. In a wide range of sectors, including new energy, rail transit, and data centers, laminated busbars, with their superior performance, are crucial for ensuring stable power transmission.



























































Laminated Copper bus bars are typically constructed from copper or aluminum. The selection of copper strictly adheres to a series of international standards, including GB T2Y2 copper, DIN E-Cu58 (No. 2.0065), EN Cu-ETP (No. CW004A), ISO Cu-ETP, UNS C11000, JIS C1100, and BS C101. These standards ensure copper purity of at least 99.99%, conductivity exceeding 97% IACS, hardness between 80 and 110 HV, and tensile strength between 245 and 345 MPa, laying a solid foundation for the busbar's high conductivity and mechanical properties.















































































Surface treatment is crucial to further enhance the Laminated BusBar for Mersen performance. After ultrasonic cleaning to ensure surface cleanliness, the surface is plated with silver, tin, or nickel, depending on the application. Silver plating significantly improves conductivity and corrosion resistance, tin plating enhances conductivity and solderability, and nickel plating improves corrosion resistance and mechanical strength. Plating thickness typically ranges from 3μm to 12μm and can be customized to meet specific customer requirements and diverse application scenarios.



Insulation performance is critical to the safe operation of Laminated Flexible BusBars, and a wide range of insulation options is available. PET insulation paper is sourced from renowned brands such as GTS in the US and KREMPEL in Germany, and is available in white or off-white. Orange and green are the most popular colors for PVC impregnation, while orange, green, and gray are common options for epoxy powder coating. PE heat shrink tubing is available in a variety of colors, including orange, green, black, red, and yellow. PA66 plastic casings are mostly available in white and gray. All insulation options meet UL94-V-0 flame retardancy/fire resistance standards and can be customized to meet customer needs, ensuring insulation reliability in diverse environments.



The Laminated Bus Bar for Telecoms offers excellent performance and stable operation over a wide temperature range of -45°C to +150°C. They feature a resistance of ≤0.00001Ω, a load voltage range of 3500VDC to 5000VDC, and a load current range of 100A to 2000A, fully meeting the needs of diverse power systems.



For customer testing and evaluation, free samples of 1-10 pieces are provided. Order delivery takes 7-10 days, and sample delivery takes 10-20 days, including tooling/mold production for copper stamping parts. Packaging utilizes inner EPE foam/blister packaging and outer cartons/pallets to ensure BusBar with PET Insulating Paper during transportation. Furthermore, these products are certified to ISO9001, IATF16949, RoHS, and REACH, demonstrating superior quality management and regulatory compliance. With robust production capacity, monthly production can reach 50,000,000 units, enabling us to meet the demands of large-scale orders.

















































































Laminated Bus Bars for Computers have a wide range of applications, including film capacitors for new energy electric and hybrid vehicles, new energy vehicle battery packs, new energy photovoltaic energy storage, electrical appliances, distribution cabinets, rail transit, and uninterruptible power supplies for cloud servers. Their design offers high flexibility and can be customized to meet specific customer needs, meeting diverse shape, size, and performance requirements. High conductivity is a key advantage. Using high-quality conductive materials and advanced manufacturing processes, the busbars offer high conductivity and low resistance, effectively improving power transmission efficiency. Excellent insulation performance is achieved through a variety of insulation treatments, providing reliable insulation protection and preventing current leakage and electrical accidents. The compact laminated design results in a compact structure, saving space and facilitating installation and maintenance. Through rigorous quality control and testing, the product boasts excellent mechanical and electrical properties, enabling long-term stable operation in harsh environments with exceptional reliability.















































































Looking ahead, with the booming development of the new energy industry, demand for efficient and reliable power distribution components is growing in sectors such as new energy vehicles and photovoltaic energy storage. Laminated Busbar SIC Applications, with their superior performance, will play an even more important role in these areas. In the rail transit sector, increasing requirements for power system stability and safety present a promising future for Laminated Bus Bar for Variable Frequency Drives. The rapid expansion of data centers, including cloud servers, also creates a vast market for BusBar for Electric Welding Machines. With continuous technological advancements, laminated busbars will continue to innovate in materials, design, and manufacturing processes, further enhancing performance and expanding their application potential. They will become an indispensable key component in the power electronics field, providing strong support for the efficient and stable operation of various power systems.
