Technical Overview of New Energy Vehicle Film Capacitor BusBar Industry

In high-voltage electrical architecture, the primary task of busbars is to achieve efficient transmission of large currents. The current high-voltage platforms of mainstream electric vehicles generally cover the range of 300V to 800V. The busbar needs to carry hundreds of amperes of continuous current, and its conductive performance directly determines the energy transmission efficiency of the entire vehicle. At the same time, the busbar serves as the electrical connection center, integrating key high-voltage components such as battery modules, inverters, drive motors, and charging interfaces into a complete electrical network. Compared with traditional wiring harness solutions, the busbar can effectively suppress energy loss and temperature rise due to its lower resistance characteristics, which is of significant significance to improving the vehicle's cruising range and thermal management efficiency.

























































The material system of busbars shows a diversified development trend. With its excellent conductivity and extremely low resistance characteristics, automotive power busbars are still the preferred solution for high current-carrying scenarios. However, their high density results in a relatively large weight, and the cost of raw materials is relatively high. Aluminum rows are widely used in medium and low current-carrying scenarios due to their lightweight advantages and cost competitiveness, which are only one-third of the density of copper. However, their conductivity is relatively weak and needs to be compensated by increasing the cross-sectional area. Composite busbar solutions, such as copper-aluminum composite structures or surface silver plating or nickel plating, are becoming the mainstream technology route to balance performance and cost.

At the structural level, flat design is a key feature for the Busbar Insulation to adapt to the compact space layout of the battery pack, which can minimize space occupation and optimize heat diffusion paths. Insulation treatment cannot be ignored either. The busbar surface is usually covered with an insulating layer such as epoxy resin coating or heat shrink tubing to eliminate the risk of a short circuit in high-voltage environments.













































































Insulated BusBars manufacturing covers multiple precision process links. The stamping and bending process enables customized molding according to the vehicle layout requirements; laser welding technology is used in key connection parts to ensure extremely low contact resistance and long-term reliability; insulating packaging is completed through injection molding or coating processes to provide comprehensive electrical isolation protection for the busbar.













































































The industry is currently developing in the direction of lightweighting (the application of aluminum busbars and composite materials is increasing), integration (integrating with fuses, current sensors, etc. to reduce connection nodes) and high voltage (the promotion of 800V platforms has increased insulation and voltage withstand requirements). Tin-plated copper busbar for EV is increasingly used in high-voltage platforms, balancing conductive efficiency and environmental resistance.
